Power Cable Routing (SR1530HCL/SR1530HCLS and
SR1530HCLR/SR1530HCLSR)
A.
Main power
B.
Processor power
C.
Backplane power
D.
Drive power daisy cable:
–
Figure 98. Power Cable Routing (SR1530HCL/SR1530HCLS and
Server System User Guide
D
F3: end connector to optical drive
SR1530HCLR/SR1530HCLSR)
A
C
B
E
AF001653
E.
System blower #1
F.
System blower #2
G.
Auxillary power signal
99
