Clearing the Password

If the user or administrator password(s) is lost or forgotten, moving the password clear
jumper into the "clear" position clears both passwords. The password clear jumper must
be restored to its original position before a new password(s) can be set.
1. Power down the system and disconnect the AC power.
2. Open the server chassis.
3. Move the jumper from the normal operation position, Password Clear Protect,
covering pins 1 and 2 to the Password Clear Erase position, covering pins 2 and 3.
See
PASSWORD CLR
J1C4
4. Reconnect the AC power.
5. Power up the system.
6. Power down the system and disconnect the AC power.
7. Return the Password Clear jumper to the Password Clear Protect position, covering
pins 1 and 2.
8. Close the server chassis.
9. Reconnect the AC power and power up the server.
Server System User Guide
Figure 13.
1-2: Normal
Operation (Default)
3
2-3: CLEAR
PASSWORD
3

Figure 13. Clear Password Jumper

AF000657
