Table 1. Intel Server System SR1530CL / SR1530HCL / SR1530HCLS and
Intel Server System SR1530CLR / SR1530HCLR / SR1530HCLSR Feature
Feature
Dimensions (SR1530CL/
SR1530CLR)
Dimensions (SR1530HCL/
SR1530HCLS and
SR1530HCLR/
SR1530HCLSR)
Server Board
Processor
Memory
Chipset
Peripheral Interfaces
I/O Control
Video
LAN
2
summarizes the features of the server system.
Summary
•
1.69 inches high (4.29 centimeters)
•
17 inches wide (43.18 centimeters)
•
20 inches deep (50.80 centimeters)
•
22 pounds
•
1.70 inches high (4.325 centimeters)
•
16.92 inches wide (43.0 centimeters)
•
25.51 inches deep (64.80 centimeters), excluding hard drive
carrier, front control panel bezel, rack handles, and front bezel
•
23 pounds
®
One Intel Server Board S5000VCL/S5000VCLR
Support for up to two Dual-Core Intel
series or 5300 (80-W versions only) series with a 1333 or 1066
MHz front side bus
•
Memory mirroring and memory sparing options
•
Six slots supporting FBDIMM 667-MHz memory
•
12 GB maximum memory
®
Intel 5000V Chipset, consisting of
•
®
Intel 5000V Memory Controller Hub
•
®
Intel 6321ESB I/O Controller Hub
External connections:
•
Stacked PS/2 ports for keyboard and mouse
•
DB9 Serial A port
•
Two NIC connectors for 10/100/1000 Mb connections
•
Two USB 2.0 ports
Internal connections:
•
One USB port header, which supports two USB 2.0 ports
•
(SR1530CL/SR1530HCL) Six SATA-150 connectors with
integrated RAID 0/1/10 support
•
(SR1530HCLS) Four SAS connectors and two SATA
connectors
•
One ATA-100 connector
•
SSI-compliant 24-pin control panel header
SMSC* SCH5027 controller
On-board ATI* RAGE video controller with 16 MB SDRAM
•
®
Intel 10/100/1000 82573E Gigabit Ethernet Controller
•
®
Intel 10/100/1000 82541PI Gigabit Ethernet Controller
Description
® ®
Xeon processors 5100
Server System User Guide
