5. Remove the screw at the back of the server system, next to the AC power input.
Save this screw. You will re-insert it later (see letter "A" in the following figure).
Lift up slightly on the front of the power supply until it clears the foot at the bottom
of the chassis (see letter "B").
Slide the power supply forward (see letter "C") and then lift it from the chassis.
.
A
B
C
B
AF000994
Figure 74. Removing Power Supply from the Server System (SR1530CL/
SR1530CLR)
Server System User Guide 75
