Table 8-2 HP Jetdirect Configuration (continued)
Message
MODEL NUMBER:
HARDWARE ADDRESS:
FIRMWARE VERSION:
LAA
PORT CONFIG:
AUTO NEGOTIATION
MANUFACTURING ID:
S/N:
DATE MANUFACTURED:

Security Settings

Information in this section of the Jetdirect configuration page is described in
Settings.
122 Chapter 8 HP Jetdirect Configuration Pages
Description
I/O CARD INITIALIZING, or INITIALIZING: The HP Jetdirect print server is initializing
the network protocols. For more information, see the status line for each protocol on
the configuration page.
I/O CARD NOT READY, or ERROR: There is a problem with the print server or its
configuration.
An error code and message is displayed if the print server is not ready. For more
information, see Table 8-12 Error
The model number of the HP Jetdirect print server (for example, J7961A)
The 12-digit hexadecimal network hardware (MAC) address of the HP Jetdirect print
server installed in the printer or device. This address is assigned by the manufacturer.
The firmware revision number of the HP Jetdirect print server currently installed in
the printer.
The Locally Administered Address (LAA) identifies the user-specified LAN hardware
address of a print server, which may be required by some network adiministrators.
The default address is the print server's factory-default LAN hardware address.
Identifies the link configuration of the RJ-45 port on the HP Jetdirect wired Ethernet
print server:
10BASE-T HALF: 10 Mbps, half-duplex
10BASE-T FULL: 10 Mbps, full-duplex
100TX HALF: 100Mbps, half-duplex
100TX-FULL: 100Mbps, full-duplex
1000T-FULL: 1000 Mbps, full-duplex
UNKNOWN: The print server is in an initialization state.
DISCONNECTED: A network connection has not been detected. Check network
cables.
Identifies whether IEEE 802.3u Auto-negotiation on the HP Jetdirect 10/100/1000–T
port is enabled (ON) or disabled (OFF).
ON (default): The HP Jetdirect print server will attempt to automatically configure
itself onto the network at the proper speed (10, 100, 1000 Mbps) and mode (half or
full duplex). Auto-negotiation is enabled after a cold reset.
OFF: You must manually configure the speed and mode using the EIO menu from
the printer's control panel. If Auto-negotiation is off, the settings must match those of
the network for proper operation.
The manufacturing identification code for use by HP online support personnel.
The serial number of the HP Jetdirect print server.
Identifies the date of manufacture of the HP Jetdirect print server.
Messages.
Table 8-3 Security
