Table 4-12 Miscellaneous Settings (continued)
Item
9100 Config
FTP Printing
LPD Printing
IPP Printing
Link settings
Locally Administered Address
Syslog Facility
Dynamic Raw Port Setting
ENWW
Description
NOTE If this parameter is disabled, other protocols that use multicast
protocols, such as mDNS and SLP, may also be disabled without notification.
Enable or disable port 9100 services. Port 9100 is an HP-proprietary raw TCP/IP port
on the HP Jetdirect print server and is the default port for printing. It is accessed by HP
software (for example, the HP Standard Port).
Enable or disable File Transfer Protocol services available on the HP Jetdirect print
server for printing. For more information, see
Enable or disable the Line Printer Daemon services on the HP Jetdirect print server.
LPD on the HP Jetdirect print server provides line printer spooling services for TCP/IP
systems. For more information, see
Enable or disable the Internet Printing Protocol on the HP Jetdirect print server. If the
printer is properly connected and accessible, IPP allows printing to this device over the
Internet (or intranet). A properly configured IPP client system is also required. For
information on IPP client software, see
(For wired 10/100/1000T Ethernet) Sets the print server's link speed (10, 100, 1000
Mbps) and communication mode (Full- or Half-Duplex). The available link-speed
selections depend on the print server model. The selections that may be displayed are
listed below.
CAUTION If you change the link setting, network communications with the
print server and network device may be lost.
■ AUTO (default): The print server uses auto-negotiation to configure itself with the
highest link speed and communication mode allowed. If auto-negotiation fails,
either 100TX HALF or 10TX HALF is set depending on the detected link speed of
the hub/switch port. (A 1000T half-duplex selection is not supported.)
■ 10T-Full: 10 Mbps, Full-duplex operation.
■ 10T-Half: 10 Mbps, half-duplex operation.
■ 100TX-Full: 100 Mbps, full-duplex operation.
■ 100TX-Half: 100 Mbps, half-duplex operation.
■ 100TX-AUTO: Limits auto-negotiation to a maximum link speed of 100 Mbps.
■ 1000T FULL: 1000 Mbps, full-duplex operation.
Specifies a locally administered address (LAA) that replaces the factory-assigned LAN
Hardware (MAC) address. If LAA is used, a user-specified string of exactly 12
hexadecimal digits must be entered.
For Ethernet print servers, the LAA address must start with hexadecimal X2, X6, XA, or
XE, where X is any hexadecimal digit 0 through F.
The default address is the factory assigned address.
Specify the encoded source facility of a message (for example, to identify the source of
selected messages during troubleshooting). By default, the HP Jetdirect print server
uses LPR as the source facility code, but local user values of local0 through local7 can
be used to isolate individual or groups of print servers.
Allows additional ports to be specified for printing to TCP port 9100. Valid ports are
3000 to 9000, which are application-dependent.
FTP Printing.
LPD Printing.
HP Software Solutions Summary.
