Table 3-2
TFTP Configuration File Parameters (continued)
number or host IP address, and mask is an address mask of bits applied to the network number and host address to
verify access. Up to 10 access list entries are allowed. If there are no entries, all hosts are permitted access. For
example,
allow: 192.0.0.0 255.0.0.0 allows hosts on network 192.
allow: 192.168.1.2 allows a single host. In this case, the default mask 255.255.255.255 is assumed and is not required.
allow: 0 This entry clears the host access list.
For additional information, see
TCP/IP Other Settings
syslog-config:
Enables or disables syslog server operation on the print server: 0 disables, 1 (default) enables.
syslog-svr:
The syslog server's IP address. It specifies the server that the HP Jetdirect print server sends syslog messages to.
syslog-max:
Specifies the maximum number of syslog messages that can be sent by the HP Jetdirect print server on a per-minute
basis. This setting allows administrators to control the log file size. The default is 10 per minute. If it's set to zero, the
number of syslog messages is not restricted.
syslog-priority:
Controls the filtering of syslog messages sent to the syslog server. The filter range is 0 to 8, with 0 being the most
specific and 8 the most general. Only messages that are lower than the filter level specified (or higher in priority) are
reported. The default is 8, messages of all priorities are sent. If 0, all syslog messages are disabled.
syslog-facility:
A code used to identify the source facility of a message (for example, to identify the source of selected messages during
troubleshooting). By default, the HP Jetdirect print server uses LPR as the source facility code, but local user values of
local0 through local7 can be used to isolate individual or groups of print servers.
slp-config:
Enables or disables the Service Location Protocol (SLP) operation on the print server: 0 disables, 1 (default) enables.
slp-keep-alive:
Specifies a time period for the print server to send multicast packets on the network to prevent being deleted from
network device tables. Some infrastructure devices, such as switches, may delete active devices from their device
tables due to inactivity on the network. To enable this feature, set a value from 1 to 1440 minutes. Set 0 to disable this
feature.
ttl-slp:
Specifies the IP multicast "Time To Live" (TTL) setting for Service Location Protocol (SLP) packets. The default value is
4 hops (the number of routers from the local network). The range is 1–15. When set to a -1, multicast capability is
disabled.
ENWW
Security
(or syslog-srv:)
Features.
IPv4 Configuration
31
