Table 4-9 IPX/SPX Settings (continued)
Item
NDS Context
Job Poll Interval
PJL Configuration

AppleTalk

The AppleTalk tab allows you to configure selected AppleTalk settings on the HP Jetdirect print
server. See
NOTE
advertised on the network.
The HP Jetdirect print server supports AppleTalk Phase 2 only.
Table 4-10 AppleTalk Settings
Item
AppleTalk Enable checkbox
AppleTalk Name
Type
Zone
76 Chapter 4 HP Jetdirect Embedded Web Server (V.31.xx)
Description
The print server's NDS context refers to the NDS container or organizational unit that
contains the print server object. Print queue and device objects can be located anywhere
within the NDS tree, but the HP Jetdirect print server must be configured with the fully-
qualified print server object name.
For example, if the print server object is found in the container "marketing.mytown.lj", the
fully qualified print server context name (CN) is:
"OU=marketing.OU=mytown.O=lj"
(where OU is an Organization Unit container and O is an Organization container within the
NDS tree). The print server will also accept "marketing.mytown.lj".
To disable NDS support, leave this field blank.
NOTE
Specifies the time interval (seconds) that the HP Jetdirect print server will wait to check for
print jobs in a print queue.
For Printer Job Language (PJL) parameters, enable (check) or disable (clear) the
parameters provided:
■ Banner Page (for printing separator pages between print jobs)
■ End-Of-Job Notification (if received from the printer, an end-of-job message will be
forwarded to a client application)
■ Toner Low Notification (if received from the printer, the HP Jetdirect print server will
forward a "toner low" message to a client application)
Table 4-10 AppleTalk Settings
The AppleTalk parameters displayed include the AppleTalk printer types that are
Description
Enable (check) or disable (clear) the AppleTalk protocol on the print server. If AppleTalk is
enabled, AppleTalk parameters stored on the print server are displayed.
Specify the name of the printer on the AppleTalk network. If you enter a name that is already
assigned on your network, the AppleTalk name specified on the Jetdirect configuration page
will be followed by a number to indicate that it is a duplicate.
Identify the type of printer being advertised on the network. Up to two types can be
displayed (for example, HP LaserJet and LaserWriter).
Select an available AppleTalk network zone for the printer. By default, the zone currently
selected will be displayed.
NDS objects cannot be created by the embedded Web server.
for a description of items on this page.
