Network Settings

The Network Settings pages allow you to set or change configuration parameters for IPX/SPX,
AppleTalk, DLC/LLC, and
and click Apply.

IPX/SPX

The IPX/SPX tab allows you to configure IPX/SPX (Internet Packet Exchange/Sequenced Packet
Exchange) parameters on the HP Jetdirect print server for operation on a Novell NetWare or IPX/
SPX-compatible network (such as a Microsoft network). See
description of items on this page.
CAUTION
not disable IPX/SPX.
For a Novell NetWare network:
■ The embedded Web server may be used to select Queue Server Mode parameters in a Novell
Directory Services (NDS) environment.
■ You cannot create the NDS print server, printer, and queue objects using the embedded Web
server. To create these objects, use other available tools or utilities.
Table 4-9 IPX/SPX Settings
Item
IPX/SPX Enable
IPX/SPX Frame Type
SAP Interval
Print Server Name
NDS Tree Name
ENWW
SNMP protocols. To assign a parameter setting, enter the desired value
If you are using direct-mode printing over IPX/SPX on a Microsoft network, do
Description
Enables or disables the IPX/SPX protocols on the HP Jetdirect print server. If the checkbox
is empty, IPX/SPX is disabled.
Specify the IPX/SPX frame type to be used by the HP Jetdirect print server on your network.
After a frame type has been configured, all others will be counted and discarded.
■ All Frame Types (Auto): senses all frame types and configures the first one detected
(default).
■ Ethernet 802.3 (EN_8023): limits the frame type to IPX over IEEE 802.3 frames.
■ Ethernet II (EN_II): limits the frame type to IPX over Ethernet frames.
■ Ethernet 802.2 (EN_8022): limits the frame type to IPX over IEEE 802.2 with IEEE
802.3 frames.
■ Ethernet SNAP (EN_SNAP): limits the frame type to IPX over SNAP with IEEE 802.3
frames.
Specifies the time interval (in seconds) that the HP Jetdirect print server waits to send
Service Advertising Protocol (SAP) messages, which are broadcast to advertise its service
capabilities on a Novell NetWare network. To disable SAP messages, use the value "0". 60
is the default value.
Specify a NetWare printer name for the HP Jetdirect print server (alphanumeric characters
only). The default name is NPIxxxxxx, where xxxxxx are the last six digits of the HP Jetdirect
print server's LAN hardware (MAC) address.
Specify the name of the NDS tree for this device. The NDS (Novell Directory Services) tree
name refers to the name of the organizational tree used by your network. To disable NDS
support, leave this field blank.
Table 4-9 IPX/SPX Settings
Networking Tab
for a
75
