Table 8-3 Security Settings (continued)
Message
Access List:
Secure Web:

Network Statistics

Information in this section of the Jetdirect configuration page is described in
Statistics.
Table 8-4 Network Statistics
Message
TOTAL PACKETS RECEIVED:
UNICAST PACKETS RECEIVED:
BAD PACKETS RECEIVED:
FRAMING ERRORS RECEIVED:
TOTAL PACKETS TRANSMITTED:
UNSENDABLE PACKETS:
TRANSMIT COLLISIONS:
TRANSMIT LATE COLLISIONS:

TCP/IP Protocol Information

Information in this section of the Jetdirect configuration page is described below. For general TCP/IP
configuration parameters, see
124 Chapter 8 HP Jetdirect Configuration Pages
Description
Not Specified: An SNMP set community name has not been set.
Specified: A user-specified SNMP set community has been set.
(IPv4 only) Identifies whether a host access control list is configured on the HP
Jetdirect print server. A host access control list specifies the IP address of individual
systems, or IP network of systems, that are allowed access to the print server and
device.
Specified: A host access list is configured on the HP Jetdirect print server.
Not Specified: A host access list is not configured on the print server. All systems are
allowed access.
Specifies the use of encrypted communications between a browser and the HP
Jetdirect embedded Web server.
Optional (HTTPS/HTTP): Allows unencrypted communications using standard HTTP
ports, as well as encrypted communications using HTTPS (secure HTTP).
HTTPS Required: Only encrypted communications on HTTPS is allowed.
Description
Total number of frames (packets) received by the HP Jetdirect print server without
error. This includes broadcast, multicast packets, and packets specifically addressed
to the print server. This number does not include packets specifically addressed to
other nodes.
Number of frames specifically addressed to this HP Jetdirect print server. This does
not include broadcasts or multicasts.
Total number of frames (packets) received with errors by the HP Jetdirect print server.
Maximum of CRC (Cyclic Redundancy Check) errors and framing errors. CRC errors
are frames received with CRC errors. Framing errors are frames received with
alignment errors. A large number of framing errors could indicate a cabling problem
with your network.
Total number of frames (packets) transmitted without error.
Total number of frames (packets) not successfully transmitted because of errors.
Number of frames not transmitted because of repeated collisions.
Total number of frames not transmitted because a late collision occurred. Late
collisions often occur when cable lengths exceed network specifications. A large
number may indicate a cabling problem on the network.
Table 8-5 TCP/IP Configuration
Table 8-4 Network
Information. For IPv4 parameters, see
