Operating Notes; Hp Jetdirect Home Tab - HP 635n - JetDirect IPv6/IPsec Print Server Administrator's Manual

identification. Encrypted browser communications through HTTPS (secure HTTP) is required for
initial access.
Although not recommended, you can use your Internet Options menu to configure your browser
to ignore security warnings if the print server is configured to operate through HTTPS. See
Mgmt. Protocols.
4 An embedded Web server page will be displayed, either the Home page of the HP Jetdirect print
server or a device page served by the device.

Operating Notes

■ If you enter or change a configuration parameter value, click Apply to enable your change, or
click Cancel to erase your change.
■ Changes to the IP address will close the connection to the embedded Web server. To re-
establish a connection, use the new IP address.
CAUTION
printing failures for clients that have been configured to print to this printer using the
previous IP address.
■
Novell NetWare networks: On the Network Settings page, use the IPX/SPX tab to configure
Novell Directory Services (NDS) Queue Server mode parameters. Note that the embedded Web
server cannot create NDS objects (print server, printer, and print queue objects) on the Novell
server. To create these objects, use a Novell NetWare utility, such as NWAdmin, or configure the
IPX/SPX stack for NDS through HP utilities, such as HP Web Jetadmin.

HP Jetdirect Home Tab

The Home tab will display the HP Jetdirect home page if a Web server in the attached device cannot
be accessed or does not exist. The HP Jetdirect home page displays a generic printer graphic to
represent the attached device. The HP Jetdirect print server's product model, firmware version, and
network addresses are displayed along with any device information that can be retrieved.
HP Jetdirect Home Page Items
page.
Table 4-1 HP Jetdirect Home Page Items
Item
Home tab
Networking tab
Device Info
Select Language
ENWW
Changes to the IP address on the HP Jetdirect print server may result in
provides a summary of the items displayed on the HP Jetdirect home
Description
Displays the Jetdirect Home page. This tab will not appear if Web pages served by the
attached device can be accessed.
Provides access to network configuration, security, and diagnostic parameters. For
more information, see
Identifies the device (such as the model name of the printer or multifunction all-in-one
device) connected to the network through the HP Jetdirect print server.
Other information that can be retrieved from the device are also displayed (such as
Page Count, or Control Panel status). The information will vary depending on the
features of the attached device.
Appears if the HP Jetdirect Web pages support multiple languages. Supported
languages may also be selected through language preference settings in your browser.
Networking Tab.
Table 4-1
HP Jetdirect Home Tab 65
