Manual Keys

Use this page to configure encryption keys and Security Associations manually. Because the
applicable hosts will also be manually configured, authentication and dynamic key generation are not
needed. Items on this page are described below.
Table 5-8 Manual Keys page
Item
ESP SPI (256 to 4095 ASCII)
AH SPI (256 to 4095 ASCII)
Key Format
Encryption
Hash

Summary

This page provides summary information for the IPsec rule. Click Create Another Rule to define
another IPsec rule before returning to the IPsec Policy page. Or, click Finish to add all configured
rules to the IPsec Policy page.

Configuring Windows Systems

To configure IPsec on supported Windows systems, consult your system documentation, or search
for IPsec on the Microsoft Web site.
ENWW
Description
If ESP is enabled on the IPsec Protocols page, the ESP SPI (Security Parameters
Index) fields are provided. The ESP SPI is a 32-bit field in an ESP header that helps
to identify the IPsec Security Association (SA).
in: Enter a value for an SA used for received packets.
out: Enter a value for an SA used for transmitted packets from the print server.
If AH is enabled on the IPsec Protocols page, the AH Security Parameters Index
(SPI) edit fields are provided. An AH SPI is a 32-bit field in an Authentication header
that helps to identify the IPsec SA.
in: Enter a value for an SA used for received packets.
out: Enter a value for an SA used for transmitted packets from the print server.
CAUTION The use of IPsec AH may not function properly in environments
that use Network Address Translation (NAT).
Choose whether you will use Hexadecimal values or ASCII characters to specify
Encryption or Hash entries.
Enter the Encryption keys for packets received (in) or sent (out) by the print server.
Enter the Hash keys for packets received (in) or sent (out) by the print server. The
Hash keys must be the same for ESP and AH protocols if both are enabled.
Configuring Windows Systems 105
