Diagnostics
Diagnostics
The Diagnostics menu provides feedback on the connection status of the device. The individual tests are
listed below. If a test displays a fail status:
1 Click on the Help link and follow the troubleshooting procedures in the Help screen that appears.
2 Now click Rerun Diagnostic Tests at the bottom of the screen to re-test and confirm the error.
3 If the test continues to fail, contact Technical Support.
F i e l d D e s c r i p t i o n
LAN# Connection PASS
port of the router.
FAIL
computer.
Wireless PASS
Connection Test
FAIL
Wi-Fi 6 CloudMesh Hybrid Gateway – User Guide
UG01445 v1.01 27 October 2023
Figure 121 – Diagnostics – Diagnostic tests
– Indicates the Ethernet connection to your computer is connected to the LAN
– Indicates that the router does not detect the Ethernet interface of your
– Indicates that the wireless card is switched ON.
– Indicates that the wireless card is switched OFF.
Table 26 – Diagnostic test result table
