After 1ms of burst data at full gigabit speed, the speed is shaped to 200Mbps.
I t e m
Interface
Type
Shaping Rate
Burst Size
Apply/Save button
Note: 1 byte = 8 bits
Routing
The Default Gateway, Static Route, Policy Routing and Dynamic Route settings can be found in the Routing
option of the Advanced menu.
Default Gateway
Select your preferred WAN interface from the available options.
Use the arrow buttons to move the available Routed WAN Interfaces listed on the right to the group of
required Default Gateway Interfaces in the list on the left.
Wi-Fi 6 CloudMesh Hybrid Gateway – User Guide
UG01445 v1.01 27 October 2023
Figure 91 – QoS Port Shaping settings
D e s c r i p t i o n
Identifies the interface type.
Identifies the connection type.
The speed you would limit the port to in Kbps (Kilobits per second) after the burst
size.
Burst size should be more than 10x MTU (>=15000 bytes)
Click to save and apply your changes
Figure 92 – Advanced – QoS – Port Shaping settings
