LAN
IPv4 Autoconfig
The LAN window allows you to modify the settings for your local area network (LAN).
The following options are available to configure:
P a r a m e t e r D e f i n i t i o n
IP Address Enter the Local IP Address to use for the CloudMesh Gateway.
Subnet Mask Enter the subnet mask to define the subnet of the Local Network.
Enable IGMP Enable IGMP Snooping and select the IGMP Snooping mode to use. Standard: allow
Snooping all multicast traffic to LAN clients. Blocking: only allow multicast subscribed clients to
receive multicast packets.
Enable LAN side Enable the LAN side firewall to restrict traffic between LAN host-LAN hosts and WiFi
Firewall Clients.
Enable DHCP Select to enable or disable the DHCP server and enter the start and end address for
Server the DHCP IP Address pool.
Wi-Fi 6 CloudMesh Hybrid Gateway – User Guide
UG01445 v1.01 27 October 2023
Figure 66 – LAN setup -- IPv4 Autoconfig settings
Table 9 – IPv4 Autoconfig settings table
