IP Version
Dest IPv4 Address
Source IPv4
Address
Dest IPv6 Address
Source IPv6
Address
Protocol
Source Port
Source Port Range
Max
Dest Port
Dest Port Range
Max
Apply/Save button
Quality of Service
Quality of Service offers a defined level of performance in a data communications system - for example the
ability to guarantee that video traffic is given priority over other network traffic to ensure that video
streaming is not disrupted by other network traffic. This means that if you are streaming video and someone
else in the house starts downloading a large file, the download won't disrupt the flow of video traffic.
To enable QoS select the Enable QoS checkbox and set the Default DSCP (Differentiated Services Code Point)
Mark. Then press the Apply/Save button.
Wi-Fi 6 CloudMesh Hybrid Gateway – User Guide
UG01445 v1.01 27 October 2023
Select: IPv4, IPv6 or IPv4/IPv4
The destination address when IPv4 or IPv4/IPv6 is the selected version.
The source address when IPv4 or IPv4/IPv6 is the selected version.
The destination address when IPv6 or IPv4/IPv6 is the selected version.
The source address when IPv4 or IPv4/IPv6 is the selected version.
Select: TCP, UDP or TCP/UDP
Specify a source port.
Specify a range of possible source ports.
Specify a destination port.
Specify a range of possible destination ports.
Press the Apply/Save button to save the firewall rule and add it to the Chain Rule
table, see previous.
Table 15 – Advanced – Firewall – Add Firewall rule
Figure 85 – Advanced – Enable QoS
