Appendix: Quality of Service setup example
The following Quality of Service (QoS) settings offer a basic setup example, setting up 2 devices connecting to
a CloudMesh Gateway, one with the highest priority for data and the other with the lowest priority for data.
All other data packet traffic through the router assumes a default best effort setting.
Quality of Service refers to the reservation of bandwidth resources on the CloudMesh Gateway to provide
different priorities to different applications, users or data flows or to guarantee a certain level of
performance to a data flow.
In this implementation, QoS employs DSCP (Differentiated Services Code Point), a computer networking
architecture that specifies a simple, scalable and course-grained mechanism for classifying and managing
network traffic.
This example guide sets up QoS with two devices (PC and laptop) connecting via Ethernet cable to a
CloudMesh Gateway. One device (PC) is assigned high priority traffic while the other device (laptop) is
assigned a low priority. Before Quality of Service can be implemented, the first step involves reserving an IP
address for each device, identified by their unique MAC addresses.
Reserving IP addresses
So that QoS settings, custom NAT settings, and parental control settings can be managed for each device, it
is necessary to reserve an IP address for each of the devices connecting to the CloudMesh Gateway.
Reserved IP addresses are not required to be within the DHCP server range, however they are required to
be with-in the LAN subnet range:
1 Navigate to http://192.168.20.1
2 When prompted, enter admin as both the username and password.
3 Select Advanced Setup > LAN
Wi-Fi 6 CloudMesh Hybrid Gateway – User Guide
UG01445 v1.01 27 October 2023
in a web browser.
