2 On the QoS Classification page, add a rule to limit the upstream rate, for example:
Classification Criteria:
⚫
Class Interface: LAN
⚫
Ether type: IP
⚫
Classification Results:
⚫
Class Queue: the queue that was enabled in Step 1
⚫
Set rate-limit: set according to your preference
⚫
3 Click Apply/Save.
Limiting the downstream rate
1 Navigate to the QoS Queue Configuration page to add a queue for the LAN interface, for example:
Wi-Fi 6 CloudMesh Hybrid Gateway – User Guide
UG01445 v1.01 27 October 2023
Figure 152 – QoS Queue details
Figure 153 – Network Traffic Class Rule
