Index(h)
2000 Reserved
2001 Axis-1 Parameter
Indicates the setting item of the Axis-1 Parameter.
SubIndex(h)
01
02
03
09
2002 Axis-2 Parameter
Indicates the setting item of the Axis-2 Parameter.
SubIndex(h)
01
02
03
09
Name
Axis Unavailable
Error Clear
Position Data Increase
Direction
Preset Value
Name
Axis Unavailable
Error Clear
Position Data Increase
Direction
Preset Value
Name/Description
Description
Specify "Available" or "Unavailable" for the axis-1.
0: Available (Default)
1: Unavailable
Specify "Error recovery behavior" for the axis-1.
0: Auto clearing (Default)
Automatically clears the error when removing the cause
of the error.
1: Manual clearing
Specify the axis-1 ABSOCODER sensor rotation direction
in which the position data increases.
0: CW (Default)
1: CCW
Specify "Preset Value" for the axis-1.
A previous setting value is read out when reading "Preset
Value".
Description
Specify "Available" or "Unavailable" for the axis-2.
0: Available (Default)
1: Unavailable
Specify "Error recovery behavior" for the axis-2.
0: Auto clearing (Default)
Automatically clears the error when removing the cause
of the error.
1: Manual clearing
Specify the axis-1 ABSOCODER sensor rotation direction
in which the position data increases.
0: CW (Default)
1: CCW
Specify "Preset Value" for the axis-2.
A previous setting value is read out when reading "Preset
Value".
