(3) EtherCAT network error
PON RUN ERR L/A
ON - - ON
ON - - OFF
ON OFF -
ON BL -
ON SF -
ON SF DF
ON BL BL
ON SF BL
ON SF SF
Name
EtherCAT Link established
EtherCAT Link not
established
- INIT state
PRE-OPERATIONAL
-
state
SAFE-OPERATIONAL
-
state
Watchdog Timer Error for
SyncManager
-
Note
The default value of the
watch dog timer is 100ms
Synchronous Cycle Setting
-
Error
-
Synchronous Error
-
Cause
The operation is waiting state after
Link is established.
- Link isn't established.
- EtherCAT master doesn't start.
- LAN hardware failure
Receives INIT state transition
instruction from EtherCAT master
Receives PRE-OPERATIONAL
state transition instruction from
EtherCAT mater
Receives SAFE-OPERATIONA
state transition instruction from
EtherCAT master.
- Link isn't established.
- LAN hardware failure
- LAN cable is severed.
- LAN cable is affected by an
excessive noise.
Synchronous cycle setting has an
error.
- Communication cable is severed.
- LAN cable is affected by an
excessive noise.
60
Countermeasure
－
- Check whether the LAN cable is wired
correctly.
- Check whether the LAN cable is
severed and connector is
disconnected.
- LAN cable length should be 100m or
less.
- Check whether LAN cable is compliant
to the Industrial Standard.
- Check whether the EtherCAT master
operates normally.
After checking above factors, the LAN
hardware might have a malfunction if the
operation is not back to normal. Thus,
replace NCW-3DNEC.
Check the EtherCAT master status if
these errors occur while operating the
system.
- Check whether the LAN cable is wired
correctly.
- Check whether the LAN cable is
affected noises.
Remove above error factors, and do
"active configuration" by EtherCAT
master.
Hardware might have a malfunction if the
operation is not back to normal. Thus,
replace the NCW-3DNEC.
Do "active configuration" by the EtherCAT
master after setting the synchronous
cycle correctly.
- Check whether the LAN cable is wired
correctly.
- Check whether the LAN cable is
affected noises.
Remove above error factors, and do
"active configuration" by EtherCAT
master.
Hardware might have a malfunction if the
operation is not back to normal. Thus,
replace the NCW-3DNEC.
