NSD ABSOCODER NCW-3DNECMP Specifications & Instruction Manual page 71

● Circuit resistance check
[Measurement method]
Measure resistance at Point A or B using a circuit tester or other appropriate device.
If the connector is off, identify the line by the wiring color.
[Check details]
Refer to the previous page for the connector pin number.
Check position
Between brown and red
Between orange and yellow
Between green and blue
Between violet and gray
*1: If checks are done at Point B, the measurement value is [Standard coil resistance + extension sensor
cable resistance (cable length (m) x 0.2 (Ω))].
The resistance value of the NSD special cable is 0.2Ω/m (loop resistance).
Consider resistance variations due to temperature, which, relative to the standard temperature (25
increases 0.4% when the temperature rises 1
● Insulation check
[Measurement method]
Measure using a 500 VDC insulation tester.
[Check details]
Refer to the previous page for the connector pin number.
Between brown and orange, green, violet, shield
Between orange and green, violet, shield
Between green and violet, shield
Between violet and shield
Between frame and each wire
NOTES
1. Make sure to disconnect the ABSOCODER sensor from NCW-3DNEC before carrying out insulation checks.
2. If there is a risk that energization may cause damages to the electronic circuits in and around the machine,
remove the ABSOCODER sensor from the machine.
3. After completing the checks, short-circuit between the pins to discharge remaining voltage before
connecting the ABSOCODER sensor to NCW-3DNEC.
Criterion
Between brown and orange, green, violet, shield
The measured
Between orange and green, violet, shield
value should be in
the range of the Between green and violet, shield
standard coil Between violet and shield
resistance. *1
Between frame and each wire
Check position
64
Check position
o
C and decreases 0.4% when the temperature falls 1
Criterion
10MΩ or more
Criterion
∞
o
C),
o
C.
