13. ABSOCODER Sensor Check List
●Applicable ABSOCODER sensor models
MRE-32SP062
MRE-G[ ]SP062
●Connection configuration
ABSOCODER
sensor
MRE-32SP062
MRE-G[ ]SP062
Checks at Point B should be carried out with Point A connected.
● Connector pin position and standard coil resistance ranges (at 25℃)
Connector Signal
pin No. name
1 SIN+
2 SIN-
3 -COS+
4 -COS-
5 OUT1+
6 OUT1-
7 OUT2+
8 OUT2-
9 Shield
－
The above standard coil resistance ranges are referential data to assist wiring disconnection diagnosis and are not
product specification values. There may be no wiring disconnection even when the resistance measurement is out
of the standard resistance range.
[ ]: 64, 128, 160, 256, 320
Extension sensor cable
Wiring color
Brown
Red
Orange
Yellow
Green
Blue
Violet
Gray
Shield
－ －
●Connector appearance and pin
NCW-3DNEC
Standard coil resistance [Ω]
MRE-32SP062
100 to 120
100 to 120
4 to 10
113 to 137
－
63
position
A
View A
MRE-G[ ]SP062
115 to 123
115 to 123
28.5 to 40.5
28.5 to 40.5
－
