NSD ABSOCODER NCW-3DNECMP Specifications & Instruction Manual page 86

Index(h)
1A01:12 SubIndex 018
1A01:13 SubIndex 019
1A01:14 SubIndex 020
1A02:0 TxPDO-Map Axis-2 Status
1A02:01 SubIndex 001
1A02:02 SubIndex 002
1A02:03 SubIndex 003
1A02:04 SubIndex 004
1A02:05 SubIndex 005
1A02:06 SubIndex 006
1A02:07 SubIndex 007
1A02:08 SubIndex 008
1A02:09 SubIndex 009
1A02:0A SubIndex 010
1A02:0B SubIndex 011
1A02:0C SubIndex 012
1A02:0D SubIndex 013
1A02:0E SubIndex 014
1A02:0F SubIndex 015
1A02:10 SubIndex 016
1A02:11 SubIndex 017
1A02:12 SubIndex 018
1A02:13 SubIndex 019
1A02:14 SubIndex 020
1C00:0 SyncManager Type
1C00:01 SubIndex 001
1C00:02 SubIndex 002
1C00:03 SubIndex 003
1C00:04 SubIndex 004
1C12:0 SyncManager CH.2 RxPDO Assign
1C12:01 SubIndex 001
1C12:02 SubIndex 002
1C13:0 SyncManager CH.3 TxPDO Assign
1C13:01 SubIndex 001
1C13:02 SubIndex 002
1C13:03 SubIndex 003
1C32:0 SyncManager CH.2 Output Parameter
1C32:01 Synchronization Type
1C32:02 Cycle Time
1C32:03 Reserved
1C32:04 Synchronization Types supported
1C32:05 Minimum Cycle Time
1C32:06 Calc and Copy Time
1C32:07 Reserved
1C32:08 Get Cycle Time
Name
PDO Map
PDO Map
PDO Map
UINT8
PDO Map
PDO Map
PDO Map
PDO Map
PDO Map
PDO Map
PDO Map
PDO Map
PDO Map
PDO Map
PDO Map
PDO Map
PDO Map
PDO Map
PDO Map
PDO Map
PDO Map
PDO Map
PDO Map
PDO Map
UINT8
UINT8
UINT8
UINT8
UINT8
UINT8
UINT16
UINT16
UINT8
UINT16
UINT16
UINT16
UINT8
UINT16
UINT32
UINT16
UINT32
UINT32
UINT16
79
Access sign RW: Read/Write
Data Type Access
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO
RW
RO
RO
RO
RO
RW
RO: Read Only
Default
3001h:12h,1
3001h:13h,1
3001h:14h,8
10
3002h:01h,32
3002h:02h,32
3002h:03h,1
3002h:04h,1
3002h:05h,1
3002h:06h,1
3002h:07h,1
3002h:08h,1
3002h:09h,1
3002h:0Ah,1
3002h:0Bh,8
3002h:0Ch,1
3002h:0Dh,1
3002h:0Eh,1
3002h:0Fh,1
3002h:10h,1
3002h:11h,1
3002h:12h,1
3002h:13h,1
3002h:14h,8
4
01h(1):Rx Mailbox
02h(2):Tx Mailbox
03h(3):Output ProcessData
04h(4):Input ProcessData
2
1601h(5633)
1602h(5634)
3
1A00h(6656)
1A01h(6657)
1A02h(6658)
32
0001h(0)
00000000h(0)
401Fh(16415)
000186A0h(125000)
********h(*)
0000h(0)
