(7) Check that the position data is preset.
Position data of axis-1: Click "TXPDO (Input) Axis-1 Status".
Position data of axis-2: Click "TXPDO (Input) Axis-2 Status".
"Position" value in the TXPDO Axis-1 or 2 Status is changed into the Preset value.
(8) PRESET setting (current position setting) is completed.
(7)
(7)
'Box 1 (NCW-3DNECMP)'
38
(7)
