NSD ABSOCODER NCW-3DNECMP Specifications & Instruction Manual page 27

8-2-2. Contents of the data indicator area
The data indicator content is changed by the display selection switch (DISP SEL).
Selection switch of the
Monitor LED display contents
*1: The preset data which displays is the data transmitted from the master.
*2: The sensor model is a sensor code value which is registered on the ESI file.
Axis-1 sensor type
Axis-2 sensor type
Unused
*3: Converter diagnosis data
Axis-1 diagnosis data
Axis-2 diagnosis data
Converter diagnosis
data
*11: IFTMO indicates an internal I/F error occurred to NCW-3DNEC.
Data Display
7 6 5
15 14 13
23 22 21
7 6 5
DE1 SPF1 SSE1
15 14 13
DE2 SPF2 SSE2
23 22 21
IFTMO
0 0
*11
DISP SEL
0 Axis-1 position data D0-D23
1 Axis-2 position data D0-D23
2 Axis-1 preset data D0-D23
3 Axis-2 preset data D0-D23
4 Reserved
5 Reserved
6 Sensor type
7 Converter diagnosis data
8 Parameter data
9 Ethernet network transmission setting *5
A AL Status Code
B AL Status
C AL Control
D Physical Station Address
E NCW-3DNEC control information
F Reserved
4 3
Sensor code
12 11 10
Sensor code
20 19 18
0
4 3
0 0
12 11 10
0 0
20 19 18
0 0 ME
20
Display content
2 1 0
9 8
17 16
2 1 0
0 0 SE1
9 8
0 0 SE2
17 16
WDTE NRDY
*1
*1
*2
*3
*4
*6
*7
*8
*9
*10
