NSD ABSOCODER NCW-3DNECMP Specifications & Instruction Manual page 84

APPENDIX 3-3. Object Dictionary List
The list of the Object Dictionary for NCW-3DNEC is indicated below.
Index(h)
1000 Device Type
1001 Error Register
1008 Device Name
1009 Hardware Version
100A Software Version
1018:0 Identity
1018:01 Vendor ID
1018:02 Product Code
1018:03 Revision
1018:04 Serial Number
10E0:0 Device Identification Reload
10E0:01 Configured Station Alias register value
10E0:03 Reload ID-selector value
10F1:0 Error Settings
10F1:02 Sync Error Counter Limit
10F3:0 Diagnosis Handling
10F3:01 Maximum Messages
10F3:02 Newest Message
10F3:03 Newest Acknowledged Message
10F3:04 New Messages Available
10F3:05 Flags
1601:0 RxPDO-Map Axis-1 Control
1601:01 SubIndex 001
1601:02 SubIndex 002
1601:03 SubIndex 003
1601:04 SubIndex 004
1601:05 SubIndex 005
1601:06 SubIndex 006
1601:07 SubIndex 007
1601:08 SubIndex 008
1601:09 SubIndex 009
1601:0A SubIndex 010
Name
UINT32
UINT8
String
String
String
UINT8
UINT32
UINT32
UINT32
UINT32
UINT8
UINT16
UINT16
UINT8
UINT32
UINT8
UINT8
UINT8
UINT8
BOOL
UINT16
UINT8
PDO Map
PDO Map
PDO Map
PDO Map
PDO Map
PDO Map
PDO Map
PDO Map
PDO Map
PDO Map
77
Access sign RW: Read/Write
Data Type Access
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO
RW
RW
RO
RW
RO
RO
RO
RW
RO
RW
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO: Read Only
Default
00000000h(0)
00h(0)
"NCW-3DNECMP"
"*.*"
"*.**"
4
00000019h(25)
00007595(30101)
00000001h(1)
********h(*)
3
0000h(0)
0000h(0)
2
00000004h(4)
5(max:21)
10h(16)
00h
00h
FALSE
0000h(0)
10
4001h:01h,1
4001h:02h,1
4001h:03h,1
4001h:04h,1
4001h:05h,1
4001h:06h,1
4001h:07h,1
4001h:08h,1
4001h:09h,8
4001h:0Ah,32
