11-5. Diagnosis History (Diagnosis Message)
NCW-3DNEC can store maximum 16 diagnosis information such as the state transmission status and error
occurrence as a history.
The diagnosis information is sent to the EtherCAT master. The transmitted diagnosis information can be checked
on the message window in the configuration tool screen.
The diagnosis history information is deleted when turning OFF the power.
Diagnosis code (h)
(Message type)
Info (E002)
Error (E800)
Error (E800)
Error (E800)
Error (E001)
Error (E001)
Error (E003)
Error (E003)
Error (E003)
Error (E003)
Error (E003)
Error (E003)
Error (E003)
Error (E003)
Error (E003)
Error (E003)
Error (E003)
The head of each message is added the cumulative energization time of NCW-3DNEC.
NOTE
Diagnosis
code (h)
01 State Change Request From:%d To:%d
11 Sync Manager %d invalid address (%d)
12 Sync Manager %d invalid size (%d)
12 Sync Manager %d invalid settings (%d)
20 DC activation register is invalid
Configured syncType (1C32:01 or 1C33:01) not supported. Check DC registers
21
and supported.
Converter status is watchdog timer error
51
(Watchdog timer error)
Converter status is memory error
52
(Memory error)
Axis-1 sensor error is occurred
60
(Axis-1 sensor error)
Axis-1 sensor is disconnected
65
(Axis-1 disconnected sensor error)
Axis-1 sensor is not supplied power
66
(Axis-1 sensor circuit power error)
Data error is occurred at axis-1 sensor
67
(Axis-1 sensor data error)
Axis-2 sensor error is occurred
70
(Axis-2 sensor error)
Axis-2 sensor is disconnected
75
(Axis-2 disconnected sensor error)
Axis-2 sensor is not supplied power
76
(Axis-2 sensor circuit power error)
Data error is occurred at axis-2 sensor
77
(Axis-1 sensor data error)
Internal interface error is occurred
90
(Internal I/F Error)
m
Diagnosis
55
essage
