NSD ABSOCODER NCW-3DNECMP Specifications & Instruction Manual page 44

(3) "Set Value Dialog" is displayed when clicking
"Write..." button in the previous screen.
Input a desired value (Preset value) in the decimal
or hexadecimal notation, and click "OK".
(4) Click "PRESET ", and select "Online" tab.
Box 1 (NCW-3D_EC)
(5) "Set Value Dialog" is displayed when clicking
"Write..." button in the previous screen.
Input "1" in the decimal or hexadecimal notation,
and click "OK".
The position data is changed into "Preset value",
and the value is held.
(6) On the procedure (4) screen, click "Write..." button
again.
Input "0" on "Set Value Dialog", and click "OK".
By returning PRESET value to "0", "position data"
starts updating.
(4)
37
(4)
0
0x00
0
00
(3)
Preset value
(5)
PRESET
(5)
PRESET
(6)
