12. MAINTENANCE INFORMATION
NCW-3DNEC can store maintenance information to the CoE object (Index 5F00h~).
The maintenance information should be store if it is required.
Stored information can be checked when doing periodic maintenance NCW-3DNEC or having an error.
For more details, refer to "APPENDIX 3-4. Details of the Object Dictionary".
Index(h)
5F00 Power Distribution Time
5F01:0 Function
5F01:01 code
5F01:02 description
5F02:0 Location
5F02:01 code
5F02:02 description
5F03:0 Installation Date
5F03:01 code
5F03:02 description
5F04:0 Descriptor 1
5F04:01 code
5F04:02 description
5F05:0 Descriptor 2
5F05:01 code
5F05:02 description
5F06:0 Security
5F06:01 code
5F06:02 description
Data
Name
Type
UINT32
UINT8
UINT32
STRING
UINT8
UINT32
STRING
UINT8
UINT32
STRING
UINT8
UINT32
STRING
UINT8
UINT32
STRING
UINT8
UINT32
STRING
Access
RO NCW-3DNEC cumulative energization time can be check.
Unit: second
RO 2 (element number of the function information)
RW Function code
RW Function comment
Max.character No.: 58
RO 2 (element number of the location information)
RW Installation location code
RW Installation location comment
Max.character No.: 58
RO 2 (element number of the Installation Date)
RW Installation date code
RW Installation date comment
Max.character No.: 58
RO 2 (element number of the Descriptor 1)
RW Descriptor 1 code
RW Descriptor 1 comment
Max.character No.: 58
RO 2 (element number of the Descriptor 2)
RW Descriptor 2 code
RW Descriptor 2 comment
Max.character No.: 58
RO 2 (element number of Security information)
RW Security code
RW Security name comment
Max.character No.: 58
61
Description
