8. NOMENCLATURE
8-1. Part Identification
Power terminal block
Axis-1 sensor connector
Axis-2 sensor connector
(M4 screw)
Selection switch of the Monitor LED
display contents
EtherCAT connector (IN side)
EtherCAT connector (OUT side)
ID setting switch
17
Monitor LEDs
(RJ45)
(RJ45)
