NSD ABSOCODER NCW-3DNECMP Specifications & Instruction Manual page 92

Index(h)
10F1 Error Settings
Sets the error condition.
SubIndex(h)
02
10F3 Diagnosis History
Sets the diagnosis handling.
SubIndex(h)
01
02
03
04
05
Name/Description
Name
The upper limit value of the sync error counter is designated.
Sync Error
For the count specification, refer to synchronization object 1C32
Counter Limit
and 1C33.
Name
Maximum Indicates numbers of the diagnosis message which can be saved
Messages in the diagnosis history.
Newest Message Indicates SubIndex (6-21) of the newest message.
Newest
Acknowledged Indicates SubIndex (6-21) of the acknowledged message
Message
Overwriting mode（SubIndex 5, Bit4=0） ：
0: Indicates the new message was read.
New Messages 1: Indicates the new message wasn't read.
Available Acknowledging mode（SubIndex 5,Bit4=1） ：
0: Indicates all messages are acknowledged.
1: Indicate that diagnosis message can be acknowledged.
Sets the flag which control the sending history of the diagnosis
message.
Bit0: Enable Emergency sending
0: No diagnosis sending (emergency) support (default)
1: With diagnosis sending (emergency) support
Bit1: Disable info messages
0: Permission for collecting Info messages (default)
1: Prohibition for collecting Info messages
Bit2: Disable warning messages
0: Warning message collection permission (default)
1: Warning message collection prohibition
Bit3: Disable error messages
0: Permission for collecting Error messages (default)
Flags
1: Prohibition for collecting Error messages
Bit4: Mode selection for diagnosis history handling
0: Overwriting mode
Keeps overwriting if the message isn't acknowledged.
1: Acknowledging mode
It won't be overwritten if the message isn't acknowledged.
If the history buffers (16pics) are full with unacknowledged
messages, new messages will be discarded.
Bit5: Overwrite/Discard Information
0: Indicates that unacknowledged message was overwritten.
(Buffer overrun)
1: The history buffer is filled with unacknowledged messages, and
new messages are discarded.
Bit6-15: Reserved
85
