NSD ABSOCODER NCW-3DHPNM2R Specifications & Instruction Manual

For iron and steel industry
Hide thumbs

Advertisement

Quick Links

Download this manual
ZEF005960100
For Iron and Steel Industry
ABSOCODER Converter
NCW-3DHPNM2R
Specifications & Instruction Manual
Applicable sensor:
MRE-32SP061
MRE-G[ ]SP061
MRE-32SP074
MRE-G[ ]SP074
MRE-32SP097
MRE-G[ ]SP097
MRE-32SP101
MRE-G[ ]SP101

Advertisement

loading
Need help?

Need help?

Do you have a question about the ABSOCODER NCW-3DHPNM2R and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for NSD ABSOCODER NCW-3DHPNM2R

Summary of Contents for NSD ABSOCODER NCW-3DHPNM2R

  • Page 1 ZEF005960100 For Iron and Steel Industry ABSOCODER Converter NCW-3DHPNM2R Specifications & Instruction Manual Applicable sensor: MRE-32SP061 MRE-G[ ]SP061 MRE-32SP074 MRE-G[ ]SP074 MRE-32SP097 MRE-G[ ]SP097 MRE-32SP101 MRE-G[ ]SP101...

  • Page 3: Table Of Contents

    CONTENTS INTRODUCTION .......................... i COPYRIGHT ..........................i GENERAL SAFETY RULES ....................... ii REVISION HISTORY ........................iii 1. OVERVIEW ..........................1 1-1. Features ................................1 2. MODEL SELECTION WHEN ORDERING ................2 3. SPECIFICATIONS ........................4 3-1. Converter Specifications ............................ 4 3-2.
  • Page 4 9. PROFINET COMMUNICATION SETUP ................32 9-1. Procedure Before the Operation ........................32 9-2. Preparation ............................... 33 9-3. Set the Network Configuration ......................... 34 9-3-1. Installation of the GSDML file ........................34 9-3-2. Creation of the network configuration ....................... 35 9-3-3.

  • Page 5: Introduction

    INTRODUCTION Thank you very much for purchasing our product. Before operating this product, be sure to carefully read this manual so that you may fully understand the product, safety instructions and precautions. - Please submit this manual to the operators actually involved in operation. - Please keep this manual in a handy place.

  • Page 6: General Safety Rules

    - Be sure to store the converter in designed temperature and humidity 8. Disposal range, and do not exposed to direct sunlight. - Be sure to consult with NSD when the converter is stored for long CAUTION periods. - Be sure to handle the converter and ABSOCODER sensor as...

  • Page 7: Revision History

    REVISION HISTORY The Document No. appears at the upper right of this manual's cover page. Document No. Date Revision Description ZEF005960100 13, Mar., 2018 1st Edition Japanese document: ZEF005960000...
  • Page 8 - MEMO -...

  • Page 9: Overview

    Professional SP1" developed by Siemens AG, Inc.. For the details of the tool, refer to manual of the "STEP7 V14 Professional SP1". If the configuration tool is needed the definition file (GSDML file), download it from NSD website. 1-1. Features...

  • Page 10: Model Selection When Ordering

    ( PLC, Industrial PC ) PROFINET device Configuration Tool (5) GSDML File (3) Extension sensor cable (2) ABSOCODER sensor (4) Option In the case of using the NSD special cable Connector type MRE-[ ]SP061 RB-01 MRE-[ ]SP074 L type flange for...
  • Page 11 (NJW-2012-PM8, manufacturer: Nanaboshi Electric Mfg.Co,Ltd.) P: Large connector for JKPEV-S cable (NWPC-4012-Ad12, manufacturer: Nanaboshi Electric Mfg.Co,Ltd.) R: Crimping terminals for JKPEV-S cable and the NSD special cable (R1.25-4) [L]: Interconnecting sensor cable length (m): 2, 5,10, 20 G: Silicon oil injected, no code: no oil injected ◆Extension sensor cable...

  • Page 12: Specifications

    3. SPECIFICATIONS 3-1. Converter Specifications (1) General specification Items Specifications Power supply voltage 24VDC±10% (including ripple) Power consumption 10W or less 20 M-Ohms or more between external DC power terminals and ground Insulation resistance (by 500 VDC insulation resistance tester) Withstand voltage 500 VAC, 60Hz for 1 minute between external DC power terminals and ground 20m/s...
  • Page 13 (3) Communication specification Items Specifications Physical layer Ethernet 10Base-T, 100Base-TX, ISO/IEC 8802-3 Number of communication ports 2 (connector: RJ45) Communication speed Auto-Negotiation(100Mbit/s) Communication format Auto-Negotiation(Full Duplex) Communication cycle Minimum 2 ms time(Update time) RT Class RT Class 1 Conformance class Class B PROFINET version PN2.3...

  • Page 14: Absocoder Sensor Specification

    3-2. ABSOCODER Sensor Specification (1) MRE-[ ]SP061 Items Specifications MRE-[ ]SP061 [ ]: Total number of turns, and with a gear(G) or without gear Sensor model MRE-32SP061 [G64] [G128] [G160] [G256] [G320] Total number of turns Divisions / turn 4096 2048 1024 819.2...
  • Page 15 (2) MRE-[ ]SP074 Items Specifications MRE-[ ]SP074 Sensor model [ ]: Total number of turns, and with a gear(G) or without gear [32] [G64] [G128] [G160] [G256] [G320] Total number of turns Divisions / turn 4096 2048 1024 819.2 409.6 Total number of divisions 131072 (2 Flange-mount type: 3.5+0.1 x cable length (m) kg...
  • Page 16 (3) MRE-[ ]SP097 / MRE-[ ]SP101 Items Specifications MRE-[ ]SP097 / MRE-[ ]SP101 [ ]: Total number of turns, and with a gear (G) or without gear Sensor model [32] [G64] [G128] [G160] [G256] [G320] [G512] [G1280] [G2048] [G2560] [G3072] Total number of turns 1280 2048...

  • Page 17: Extension Sensor Cable Specification

    8-core, 2 pairs without shield + 2 pairs with shield Color Gray Black Heat treatment and Extensible for long Advantage Superior flexibility; ideal for moving place flexible; ideal for distances moving place [Remark] Contact your NSD representative when the extension cable combines different types of cables.

  • Page 18: Dimensions

    4. DIMENSIONS 4-1. Converter Dimension Units: mm Mounting hole DIN rail...

  • Page 19: Absocoder Sensor Dimensions

    4-2. ABSOCODER Sensor Dimensions (1) MRE-32SP061FK[ ] (Flange-mounting type) Units: mm (2) MRE-G[ ]SP061FK[ ] (Flange-mount type) (3) Option: RB-01 L-type flange for MRE-32SP061, MRE-G[ ]SP061...
  • Page 20 (4) MRE-[ ]SP074FK[ ] (Flange-mount type) Units: mm (5) MRE-[ ]SP074LK[ ] (Base-mount type) (6) MRE-[ ]SP074MK[ ] (Face-mount type)
  • Page 21 (7) MRE-[ ]SP097FK[ ] (Flange-mount type) Units: mm (8) MRE-[ ]SP097LK[ ] (Base-mount type)
  • Page 22 (9) MRE-[ ]SP101FK[ ] (Flange-mount type) Units: mm (10) MRE-[ ]SP101LK[ ] (Base-mount type)

  • Page 23: Extension Sensor Cable Dimensions

    4-3. Extension Sensor Cable Dimensions (1) 4P-S-0144-[L] / 4P-RBT-0144-[L] / 4P-URT-0144-[L] Units: mm NOTE: [L] is given in terms of meter. (2) 4P-S-4344-[L] / 4P-RBT-4344-[L] / 4P-URT-4344-[L] / 4P-HRT-4344-[L] NOTE: [L] is given in terms of meter. (3) 4P-S-0155-[L] / 4P-RBT-0155-[L] / 4P-URT-0155-[L] NOTE: [L] is given in terms of meter.

  • Page 24: Checking The Contents Of The Shipping Case

    5. CHECKING THE CONTENTS OF THE SHIPPING CASE Open the packing case, and verify that all items are present. When extension sensor cables are ordered, they are packed separately. ① ② ①Converter······································································· 1 unit ②Manual (Simple edition) ···················································· 1 piece...

  • Page 25: Installation

    6. INSTALLATION 6-1. Converter Installation Conditions and Precautions When installing the converter, the following conditions and precautions should be observed. -Installation Site (1) Avoid sites where the unit is exposed to direct sunlight. (2) The ambient temperature should never exceed a 0 to 55°C range. (3) The ambient humidity should never exceed a 20 to 90% RH range.

  • Page 26: Absocoder Sensor Installation Conditions And Precautions

    6-2. ABSOCODER Sensor Installation Conditions and Precautions The ABSOCODER installation procedures and precautions are described in this section. ● Handling of Turn-type ABSOCODER Sensor Item Explanation (1) Main unit (2) Cable ● Mounting of Turn-type ABSOCODER Sensor Item Explanation Precaution (1) Mounting For details regarding mounting dimensions, refer to each ABSOCODER dimensions.
  • Page 27 ● Mounting of Turn-type ABSOCODER Sensor Item Explanation Precaution (1) Coupling of machine A “direct-link” format will shaft and sensor result in shaft fatigue shaft and / or breakage after long periods. Therefore, be sure to use a coupling device to link the shafts.
  • Page 28 ● Coupling of Turn-type ABSOCODER Sensor Item Explanation Precaution (1) Coupling device The selection of a larger selection precaution coupling than necessary will increase the shaft load which is caused by the mounting error amount. Excessive force applied to the shaft can deform the coupling and reduce durability.

  • Page 29: Wiring

    7. WIRING 7-1. Connection between Converter and ABSOCODER Sensor The maximum extension sensor cable length varies according to the ABSOCODER sensor and cable model being used. For more details refer to “3-2. ABSOCODER Sensor Specifications". -Wiring Precautions (1) The sensor cable should be clamped as shown in the right figure to prevent excessive tension from Cable clamp being applied to the cable connectors.

  • Page 30: Connection Configure Example Of The Sensor Cable

    7-1-1. Connection configure example of the sensor cable ● In the case of using the NSD special cable ABSOCODER sensor Extension sensor cable Converter...
  • Page 31 ● In the case of using the commercially available cable (JKPEV-S 1.25mm2×5P) and connecting with crimping terminals Please install the crimping terminals by customers Converter JKPEV-S Cable cross section ABSOCODER sensor Commercially available cable NSD special cable Crimping terminal Crimping terminal (R1.25-4) (R1.25-4) Crimping terminal (R1.25-4)
  • Page 32 Please install the connector by customers Converter JKPEV-S Cable cross section ABSOCODER sensor Commercially available cable NSD special cable ABSOCODER sensor JKPEV-S cable NSD special cable Connector pin No. Connector pin No. and wire color Connector pin No.

  • Page 33: Power Supply Connection

    7-2. Power Supply Connection The power supply should be connected as described below: ●Power Supply - Choose the power supply capacity which is more than twice the power consumption of the converter. The power consumption of the converter is 10W or less. Over Power +24VDC...

  • Page 34: Nomenclature

    8. NOMENCLATURE 8-1. Part Identification Monitor LEDs Selection switch of the Monitor LED display contents Power terminal block (M4 screw) Ethernet port 1 (LINK1) (RJ45) MAC address Ethernet port 2 (LINK2) E8:8E:60 (RJ45) xx:xx:xx Axis-1 sensor connector Axis-2 sensor connector...

  • Page 35: Function And Name Of Indicator And Setting Area

    8-2. Function and Name of Indicator and Setting Area Contents on the monitor LEDs are described in this section. Data Converter Communication indicator status status indicator indicator Indicator LED color Description Indicates the operation status of NCW-3DHPN. Green / Red Communication Indicates the EtherNet/IP communication status of NCW-3DHPN.

  • Page 36: Contents Of The Communication Status Indicator Area

    8-2-1. Contents of the communication status indicator area Explains the overview of the PROFINET communication status indicator area. For more details, refer to “11. TROUBLE SHOOTING”. Indicator Color Light status Description No power Steady Green Normal operation Green/Red Flashing Red A recoverable fault occurs Steady Red An unrecoverable fault occurs...

  • Page 37: Contents Of The Data Indicator Area

    8-2-2. Contents of the data indicator area The data indicator content is changed by the display selection switch (DISP SEL). DISP SEL Display content Data Display Axis-1 position data D0-D23 Axis-2 position data D0-D23 Axis-1 preset data D0-D23 Axis-2 preset data D0-D23 Reserved Reserved Reserved...
  • Page 38 *4: Ethernet network transmission setting Full LINK1 Reserved Reserved Duplex Mbps Full LINK2 Reserved Reserved Duplex Mbps IP address IP Host address [IP.ADR] 8-bit - 100Mbps light turns ON when it is normal. Lights turn OFF when an error occurs. *5: Sensor circuit control information Indicates the low-order 8-bit information of Output data (Axis-1 control flag and Axis-2 control flag) for Real-Time communication.

  • Page 39: Ethernet Port (Link1/Link2)

    8-2-3. Ethernet port (LINK1/LINK2) Ethernet communication cables are connected to these ports. Ethernet port 1 (LINK1) (RJ45) E8:8E:60 xx:xx:xx Ethernet port 2 (LINK2) (RJ45)

  • Page 40: Profinet Communication Setup

    Indicates procedure before the operation. Start setup Preparation -------- Refer to section 9-2. Download the GSDML file (XML file) from NSD web site. URL: www.nsdcorp.co.jp -------- Refer to section 9-3. Set the network configuration Set the network configuration of NCW-3DHPN.

  • Page 41: Preparation

    Professional SP1" developed by Siemens AG, Inc.. For the details of the tool, refer to manual of the "STEP7 V14 Professional SP1". ●Preparation of GDSML file If the configuration tool is needed the definition file (GSDML file), download it from NSD website. URL: www.nsdcorp.co.jp File name: GSDML-V***-NSD_Corporation-NCW3D_PN-******** ●Hardware Setup...

  • Page 42: Set The Network Configuration

    9-3. Set the Network Configuration Set the network configuration of the converter after installing the GSDML file to the configuration tool. 9-3-1. Installation of the GSDML file Install the GSDML file of the converter to the configuration tool. In the "Options" menu of the configuration tool, select the "Manage general station description files (GSD)" command.

  • Page 43: Creation Of The Network Configuration

    9-3-2. Creation of the network configuration Select the GSDML file of the product which configures the network from "Hardware Catalog" after installing the GSDML file. The GSDML file is stored in the following folders by each category. PLC ····························· Controllers Switching hub ················...
  • Page 44 Set the network configuration of the PLC and switching hub. 1. Select the PLC interface (indicated by green rectangle). Interface 2. Drag the PLC interface to the switching hub interface to connect. A line appears when dragging. 3. PROFINET IO-System is configured between PLC and switching hub after releasing the drag. 4.

  • Page 45: Set The Topology

    9-3-3. Set the topology Sets the network topology. Display the Topology view from main screen. Set the topology by following the actual network configuration. The setting method is the same as the network configuration in "9-3-2".

  • Page 46: Set Nameofstation (Device Name)

    9-4. Set NameOfStation (Device Name) The PROFINET configuration is needed setting each device name which is called "NamaOfStation". The device name is previously set as a default name to the GSDML file. Thus, the default name is displayed on the configuration tool. The configuration tool automatically adjusts the device name if the same product name exists on the network.
  • Page 47 (4) Check the box on "Generate PROFINET device name automatically" when using the default name. Remove the check-mark, and input a new device name on the "PROFINET device name" when changing the device name. (5) Set the device name to the converter. Right click on the converter image, and click "Assign device name".
  • Page 48 (6) "Assign PROFINET device name" window is appears on the screen. Click "Update list" button. The devices which can be changed the name are listed. (7) Select the converter whose device name is changed, and click the "Assign name" button. The device name is changed to the name which is set in procedure (4).

  • Page 49: Set The Ip Address

    9-5. Set the IP Address IP address for each device is automatically allocated. IP address of the converter can be changed in the following window when it needs to change. (1) In the "Device view" tab, display "IP protocol" from "General ->PROFINET Interface->Ethernet Address". (2) Change the value of "IP address".

  • Page 50: Set The Communication Cycle

    9-6. Set the Communication Cycle Sets the communication cycle between the PLC and converter. A default value of the communication cycle is set to "2ms (minimum value)". Change the communication cycle in the following window if it needed to change. (1) In the "Device view"...

  • Page 51: Set Sensor Parameter Of Ncw-3Dhpn

    9-7. Set Sensor Parameter of NCW-3DHPN Before NCW-3DHPN is used, parameters must be configured. The parameter value set at configuration tool is written to NCW-3DHPN when the communication is established for PROFINET. Note The sensor parameter can be also set from the WRREC of the PLC function. However, a value is change to it set by the configuration tool when communication is reestablished (relinking-up or restarting the power supply).

  • Page 52: Sensor Parameters Setting Procedure

    9-7-2. Sensor parameters setting procedure Setting procedures of the sensor parameter is indicated below. (1) Select "Device view->Device overview". (2) Right-click "Parameter Access Point", and click "Properties". (3) Set the sensor parameter. Set the parameter when displaying "Module Parameters". (3) 1-axis sensor parameter (3) 2-axis sensor parameter...

  • Page 53: Create Of The Ncw-3Dhpn Tag Table

    9-8. Create of the NCW-3DHPN Tag Table Create I/O data tag in "Default tag table" in order to use I/O data of NCW-3DHPN in the PLC sequence program. The I/O data tag is created for axis-1 and axis-2; however, a tag of unused axis doesn't need to create. Indicates procedures of the I/O data tag.
  • Page 54 (4) Set the data tag address. On "Operand identifier", "I" indicates the input of the I/O data, and "O" is the output. For more details, refer to the "9-8-1. I/O data format". For each address of the I/O data, check I Address and Q Address in "Device view->Device overview". (5) Create a data tag for either axis-1 or axis-2 by repeating the procedure (2) to (4).

  • Page 55: I/O Data Format

    9-8-1. I/O data format Indicates the I/O data format of NCW-3DHPN. (1) Output (Controller -> Device) Data Format (Size: 16-byte) Offset Address Data Format (Byte) Data type Name Description WORD Axis-1 Control Axis-1 Control Flags Description Reserved ERRCLR (Error Clear Command) Clears an error that is monitored from Axis-1 Status.
  • Page 56 (2) Input (Device -> Controller) Data Format (Size: 28-byte) Offset Address Data Format (Byte) Data type Name Description DWORD System Status NCW-3DHPN Diagnosis Status Description NRDY (Internal Error) Indicates that an internal error of NCW-3DHPN occurred. The hardware might have malfunction if the converter doesn't operate normally after restarting the power supply.
  • Page 57 Offset Address Data Format (Byte) Data type Name Description UDINT Axis-2 Position Axis-2 Position data Shows the Axis-2 Position data. UDINT Reserved Reserved WORD Axis-2 Status Axis-2 Status Description SE (Sensor Error) Indicates that a SSE/SPF/DE occurred. 0: No error 1: Error Reserved SSE (Disconnected Sensor Error)
  • Page 58 (3) Preset procedure Indicates PRESET procedure of the position data which is using the I/O communication data (Output). Preset Value Preset Value 100ms or more 1-cycle or more PRESET 1-cycle or more (Control Flag bit-7) 2-cycle or less Position Data Old Position data PRESET Position data PRESET Answerback...

  • Page 59: Download The Device Description File

    9-9. Download the Device Description File Download the device description file to the PLC. (1) Select the device, and Right-click. Select "Compile->Hardware and Software (only changes)" (2) Reselect the device and right-click after the compile is completed. Select "Download to device->Hardware and Software (only changes) ", and download to the PLC.
  • Page 60 (3) The following window is displayed after the download. Search the PLC which is downloaded by clicking “Start search” button. (4) Select target PLC, and click “Load” button. “Download” is executed. Downloadable PLCs are displayed after searching the device.

  • Page 61: Confirm Position Data Of Ncw-3Dhpn

    9-10. Confirm Position Data of NCW-3DHPN (1) Click "Go online" when PLC is RUN mode. (2) "Default tag table" is displayed by selecting "PLC->PLC Tag->Default tag table". (3) Current I/O data are displayed on "Monitor value" when clicking "Monitor" button. Current I/O data are displayed.

  • Page 62: Inspection

    10. INSPECTION The inspection should be conducted once every 6 months to a year. Any inspected items which do not satisfy the criteria shown below should be repaired Inspection Inspection Description Criteria Remark item Measure the voltage fluctuation at the power Power supply supply terminal block of the converter to Within 21.6V to 26.4VDC range...

  • Page 63: Trouble Shooting

    11. TROUBLE SHOOTING Explains each error which is detected by NCW-3DHPN. 11-1.Check Methods during an Error Is Occurred Error details can be checked by the indicator light status of NCW-3DHPN. More over, the error details can be checked by following method with using configuration tool "STEP7 V14 Professional SP1"...

  • Page 64: Ncw-3Dhpn Indicator

    11-3. NCW-3DHPN Indicator 11-3-1. Status indicator (MS/NS) Error contents can be checked by lighting status of the status indicator (MS/NS) when an error occurs. Check the contents and take appropriate measures. Light status Name Cause and Countermeasure Normal operation Indicates that it is in the normal communication. Green Green Flashing...

  • Page 65: Link Status Indicator (L/A1･L/A2)

    11-3-2. Link status indicator (L/A1･L/A2) The Link Status indicator (L/A1, L/A2) indicates communication state. L/A1: the Ethernet port 1 state. Indicates L/A2: the Ethernet port 2 state. Indicates Light status Name Cause and Countermeasure L/A1, L/A2 No link Indicates Link is not established. Link Indicates Link is established.

  • Page 66: Device Reset

    11-4. Device Reset The following parameter of NCW-3DHPN can be reset (factory setting) by using a configuration tool if PROFINET communication is available. A memory error (ME) which is occurred on NCW-3DHPN will be cleared if reset (factory setting) is done. Parameter Description - NameOfStation...

  • Page 67: Store Of Maintenance Information

    12. STORE OF MAINTENANCE INFORMATION NCW-3DHPN can store maintenance information. The maintenance information should be store if it is required. Stored information can be checked when doing periodic maintenance NCW-3DHPN or having an error. For more details, refer to "APPENDIX 1-2. Info Maintenance" and "APPENDIX 2. I&M DATA". Name Data Type Description...

  • Page 68: Absocoder Sensor Check List

    13. ABSOCODER SENSOR CHECK LIST ● Applicable ABSOCODER sensor models MRE-32SP061, MRE-32SP074, MRE-32SP097, MRE-32SP101 MRE-G[ ]SP061, MRE-G[ ]SP074, MRE-G[ ]SP097, MRE-G[ ]SP101 ● Connection configuration Extension sensor cable Converter ABSOCODER sensor Commercially available cable JKPEV-S (1.25mm ×5P) ● Connector appearance and pin position View View View...
  • Page 69 Extension sensor cable resistance value The resistance value of the NSD special cable is 0.2Ω/m (loop resistance). The resistance value of the JKPEV-S cable is 0.034Ω/m (loop resistance). Consider resistance variations due to temperature, which, relative to the standard temperature (25 increases 0.4% when the temperature rises 1...

  • Page 70: Ce Marking

    14. CE MARKING This product conforms to the EMC Directive. 14-1. EMC Directives It is necessary to do CE marking in the customer’s responsibility in the state of a final product. Confirm EMC compliance of the machine and the entire device by customer because EMC changes configuration of the control panel, wiring, and layout.

  • Page 71: Restrictions

    14-4. Restrictions ●Sensor cable If a 30m or longer sensor cable is to be used, pass the sensor cable through a metal duct or cover the sensor cable with the shielded zippertubing and ground the tube shield. Zippertubing Model Manufacturer ZIPPERTUBING (JAPAN), LTD.

  • Page 72: Appendix 1. Record Data

    APPENDIX 1. RECORD DATA The record data used in NCW-3DHPN is written in the GSDML file. APPENDIX 1-1. Sensor Parameter NCW-3DHPN has following sensor parameters. Access Data Index Name Description Read Write Type ○ ○ Bit0 … Axis Unavailable 0x1000 Axis-1 Sensor Parameter BYTE Specify “Enable”...

  • Page 73: Appendix 1-2. Product Operation & Error History

    APPENDIX 1-2. Product Operation & Error History The cumulative energization time, operation, and error history of NCW-3DHPN can be checked. Access Data Index Name Description Read Write Type ○ Power Distribution Time 0x3000 UDINT Indicates the cumulative energization time of NCW-3DHPN. (Unit: sec) ○...
  • Page 74 ●History Message Lists History message code (Hex) History message Message details 0x00000001 Power ON The power was applied. 0x00000002 Power FAIL Low power supply was detected. 0x00000020 LINK1 Port is LinkUP LINK1 Port was Linked up. 0x00000021 LINK1 Port is LinkDOWN LINK1 Port was Linked down 0x00000022 LINK2 Port is LinkUP...

  • Page 75: Appendix 1-3. Interface Parameter

    APPENDIX 1-3. Interface Parameter Indicates the current communication parameter of NCW-3DHPN. Access Data Index Name Description Read Write Type ○ NameOfStation 0x7000 STRING NameOfStation of device [240] (Max. 240 -octet) ○ 0x7001 IP Address BYTE IP Address of device ○ MAC Address MAC Address 0x7002...

  • Page 76: Appendix 2. I&M Data (Identification & Maintenance Data)

    APPENDIX 2. I&M DATA (Identification & Maintenance Data) I &M data indicates the product and maintenance information. These are stored in the nonvolatile memory. Access I&M I&M data Description Read Write VENDER_ID NSD_Corp “0x0417” ORDER_ID Model code of product “NCW-3DHPNM2R” SERIAL_NUMBER Serial number of product HARDWARE_REVISION...

  • Page 77: Appendix 3. Alarm Data

    APPENDIX 3. ALARM DATA The alarm data used in NCW-3DHPN is written in GSDML file. The text is displayed on the configuration tool when an alarm occurs. AlarmType Text display Description Process Axis-1 SSE Axis-1 sensor error (Disconnected Sensor Error) was detected. Axis-1 DE Axis-1 sensor error (Sensor Data Error) was detected.
  • Page 78 Manufacturer NSD Corporation 3-31-28, OSU, NAKA-KU, NAGOYA, JAPAN 460-8302 Distributor NSD Trading Corporation 3-31-23, OSU, NAKA-KU, NAGOYA, JAPAN 460-8302 Phone: +81-52-261-2352 Facsimile: +81-52-252-0522 URL: www.nsdcorp.com E-mail: foreign@nsdcorp.com Copyright©2020 NSD Corporation All rights reserved.

This manual is also suitable for:

Absocoder ncw-3dhpn
