22
en | Installation
3.3
Mounting the enclosure
3.3.1
MAP panel enclosure
Inserting the wall tamper plug
1.
2.
3.
2024-10 | V26 | F.01U.168.332
Use the supplied drill template to mark the holes on the intended surface.
The drill template can be found in the enclosure box.
If a wall tamper is required, insert the plug for the tamper switch into the back of the
enclosure (required in accordance with VdS and EN50131 grade 3) as shown in the
figure.
Secure the plug to the wall using a suitable screw (not supplied).
Installation manual
Modular Alarm Platform 5000
Bosch Security Systems B.V.
