66 en | Programming
4.
Compliance check / validation
During programming, you can check whether programming is compliant with the selected
standard at any time.
4
ð
6.2

System bundle

Fault-free operation of the MAP5000 panel can be guaranteed only if all system modules of
the MAP5000 panel and RPS for MAP comply with the manufacturer's specifications.
6.2.1

Checking the firmware version

After first start-up, you need to check whether the firmware versions of all system modules
and the RPS for MAP are compatible with each other (refer to MAP5000 system bundles).
1.
2.
3.
ð
6.2.2

Firmware updates

All system modules are updated by means of the RPS for MAP.
4
6.2.3

Manufacturer authorization

In order to transfer new firmware to the system modules with RPS for MAP, a manufacturer
authorization may be needed on the MAP5000 panel side.
1.
2.
3.
4.
6.3

Completing the installation

1.
2.
2024-10 | V26 | F.01U.168.332
Select Restore all properties using <selected standard> default property values set.
Confirm with Yes.
Click on the Panel Validation button.
Any errors found will be displayed in the Error List window in plain text.
Make a connection to the MAP5000 panel.
Click on the MAP 5000 Panel node.
The firmware version is displayed in the Properties under Control Panel Firmware
Version.
Click successively on the system modules in the Hardware Manager.
The firmware version is shown in the Diagnostics under Firmware Version.
The version of RPS for MAP is displayed during start-up or under RPS Start>RPS
Options>Resources.
To carry out updates, follow the instructions in the file How to update ... in the zip file.
Authorize the manufacturer user by a user with corresponding permissions (see
operating manual, section Manufacturer authorization).
Open the MAP5000 panel enclosure.
Activate Installer Mode (Installer button, page 72).
Log on at the Installer touch keypad with the manufacturer's passcode. The passcode is
a combination of the 3-digit user ID and a 6-digit password. Use the user ID 000 and
password 234567 when logging on for the first time. These are entered directly in
succession. The manufacturer's password can be changed after successful log-on. The
password 234567 is deactivated as a result.
Stick the type label supplied in the MAP5000 panel accessory pack on the MAP5000
panel enclosure at a location that is easily visible from outside.
Lock the enclosure door after completing all work.
