Installing the tamper switch rail

–
–
1.
2.
3.
2024-10 | V26 | F.01U.168.332
Knockout for wall tamper (required in accordance with VdS and EN50131
grade 3)
Knockout for TAE box
Knockouts for wiring
Knockout for AC wires (use when AC wires come in from the back of the
enclosure)
Side wall knockouts for wiring
Install the ICP-MAP0050 MAP panel/power enclosure tamper switch in the ICP-
MAP0111 MAP panel enclosure.
Install the ICP-MAP0055 MAP expansion enclosure tamper switch in the ICP-MAP0120
MAP expansion enclosure.
Remove the tamper switch rail from the package.
Mount the tamper switch rail to the inner right side of the enclosure as shown in the
figure below.
Secure the tamper switch rail with the two supplied screws.
Do not mount the tamper switch at this time.
