16
en | Introduction
System installation in ICP-MAP0111 MAP panel enclosure (hinged mounting plate open)
Callout
1
2
3
4
5
6
2024-10 | V26 | F.01U.168.332
Description
ICP-MAP0111 MAP panel enclosure
AT x000 communicator
ICP-MAP0050 MAP panel/power enclosure tamper switch
ICP-MAP0065 MAP terminal block
IPP-MAP0005-2 MAP power supply 150W
ICP-MAP0025 MAP hinged mounting plate
Installation manual
Modular Alarm Platform 5000
Bosch Security Systems B.V.
