18 en | Introduction
Enclosure overview
9
1
8
10
Callout
1
2
3
4
5
6
7
8
9
10
2024-10 | V26 | F.01U.168.332
9
2
3
5
4
6
7
Description
Wire trays
Wire knockouts
Mounting rails for ICP-MAP0020 MAP accessory mounting plate
Mounting location for TAE box
Knockout for wall tamper
Mounting location for ICP-MAP0065 MAP terminal block
Grounding studs
Flange for IPP-MAP0005-2 MAP power supply 150W
Shielding connection points
Knockout for AC wires (use when AC wires come in from the back of the
enclosure)
Installation manual
9
2
8 10
Modular Alarm Platform 5000
3
5
6
7
