Modular Alarm Platform 5000
Installing the hinged mounting plate
Callout
1
2
3.13.1
Mounting the modules onto the hinged mounting plate
Hinged mounting plate overview
The following graphic shows an overview of the hinged mounting plate and the designated
mounting locations of the modules.
Bosch Security Systems B.V.
Description
ICP-MAP0111 MAP panel enclosure
ICP-MAP0025 MAP hinged mounting plate
Installation manual
Installation | en
2024-10 | V26 | F.01U.168.332
37
