74 en | Technical Specifications
8

Technical Specifications

Electrical
Maximum operating voltage in VAC
Minimum AC line frequency in Hz
Maximum AC line frequency in Hz
Maximum power consumption in W per
power supply
Minimum battery capacity in Ah per power
supply
Maximum battery capacity in Ah per power
supply
Back‑up time
Frequency bands of operation
GSM900
GSM1800
Mechanical
MAP panel enclosure
Dimension in cm (H x W x D)
Weight in g
MAP power enclosure
Dimension in cm (H x W x D)
Weight in g
MAP expansion enclosure
Dimension in cm (H x W x D)
Weight in g
System parameters
Number of addresses
Number of areas
Event log capacity
Users
Number of users
2024-10 | V26 | F.01U.168.332
230 (-15 %, + 10%)
47
63
150
18
80
Determined by battery capacity and system
load. Consider time or capacity limits for
recharging the batteries regarding local
regulations or EN standards if needed.
Power level for radio equipment
Class 4 (2W) - GPRS Class 10
Class 1 (1W) - GPRS Class 10
65.8 x 44.3 x 19.35
15340
65.8 x 44.3 x 19.35
14417
43.6 x 44.3 x 11.2
8314
1500
1
500
5000
1000
