38
en | Installation
1
2
3
Callout
1
2
3
4
5
Sliding the module onto the hinged mounting plate
1.
2.
2024-10 | V26 | F.01U.168.332
Description
ICP-MAP0007-2 MAP DE interface module
ICP-MAP0010 MAP LSN gateway
ICP-MAP0012 MAP BDB/CAN splitter
MAP5000 panel
ICP-MAP0025 MAP hinged mounting plate
Slide the module onto the hinged mounting plate.
Ensure that the locking clips snap into a pair of rectangular openings on the bottom
rail.
Installation manual
Modular Alarm Platform 5000
4
5
Bosch Security Systems B.V.
