68
en | Programming
Behavior item type
Technical alarm
External system trouble
Internal system trouble
External intrusion trouble
Internal intrusion trouble
Technical trouble
Summary area armed
Area armed
Area disarmed
Area ready to arm
Internal program ON
Chime
Monitor (output follows Input)
Report failure MAP5000 panel
alarm (V1.2x)
Report failure intrusion and
tamper alarm (V1.2x)
Report failure summary alarm
Report failure summary trouble MAP5000 panel has received negative acknowledgment
Report failure duress alarm
Report failure hold-up alarm
Report failure amok alarm
Report failure intrusion and
tamper alarm
Report failure panel alarm
Internal tamper alarm
2024-10 | V26 | F.01U.168.332
Output is activated for ...
Technical alarm
Power supply failure (p), battery trouble
Power supply failure, ground fault, printer trouble
Detector self test trouble
Anti-mask trouble
Technical trouble
One or more areas armed externally
Area x armed externally
Area x disarmed externally
Area x disarmed and ready to arm
Internal program x switched on
Detector has tripped chime, only if chime mode is
activated
Shows the actual status of the input: normal / active
MAP5000 panel has received negative acknowledgment
from communicator as a result of report failure MAP5000
panel alarm (only for MAP5000 panel firmware 1.2.x or
higher)
MAP5000 panel has received negative acknowledgment
from communicator as a result of report failure intrusion
and tamper alarm (only for MAP5000 panel panel
firmware 1.2.x or higher)
MAP5000 panel has received negative acknowledgment
from communicator due to report failure summary alarm
from communicator due to report failure trouble
MAP5000 panel has received negative acknowledgment
from communicator due to report failure duress alarm
MAP5000 panel has received negative acknowledgment
from communicator due to report failure hold-up alarm
MAP5000 panel has received negative acknowledgment
from communicator due to report failure amok alarm
MAP5000 panel has received negative acknowledgment
from communicator due to report failure intrusion and
tamper alarm
MAP5000 panel has received negative acknowledgment
from communicator due to report failure panel alarm
Tamper alarm from disarmed area
Installation manual
Modular Alarm Platform 5000
