14 en | Introduction
1
Cable length
The cable length of the splitted external BDB depends on the number of added touch
keypads and of the cable diameter.
The maximum cable length is 500 m per BDB connector.
1.
2.
Relation of cable length, diameter and number of touch keypads
Cable
diameter
0.6 mm
0.8 mm
1.0 mm
Notice!
i
These cable lengths apply only for keypads with hardware version 1.0.2. The cable lengths
of older keypads are half of the lengths displayed in the table above.
Notice!
i
These cable lengths apply for keypads that are mounted with an equal cable distance in
between each other.
Refer to
–
2.5

System overview

This chapter shows an overview of the system as it is installed in the ICP-MAP0111 MAP
panel enclosure.
2024-10 | V26 | F.01U.168.332
ICP-MAP0012 MAP BDB/CAN splitter
When planning the system with one or more MAP BDB/CAN splitters, ensure to use an
appropriate cable length and diameter in accordance with the necessary number of
touch keypads.
Cascading of MAP BDB/CAN splitters is prohibited.
1
225 m
400 m
620 m
Splitting the external BDB with a BDB/CAN splitter, page 54
Number of touch keypads
2 3
225 m 200 m
400 m 350 m
620 m 550 m
Installation manual
Modular Alarm Platform 5000
4 5
150 m 120 m
275 m 220 m
450 m 360 m
Bosch Security Systems B.V.
6
100 m
200 m
300 m
