Modular Alarm Platform 5000
3
Installation
–
–
–
–
–
–
3.1
Removing the enclosure knockouts
1.
2.
Enclosure knockouts on ICP-MAP0111 MAP panel enclosure or ICP-MAP0120 MAP
expansion enclosure
5
5
4
5
Callout
Bosch Security Systems B.V.
Use proper anchor and screw sets when installing the enclosure on surfaces. Refer to
the drill template for detailed instructions.
Ensure that there is enough free space to the left of the enclosure so that the enclosure
door and the ICP-MAP0025 MAP hinged mounting plate have full range of motion.
–
For a fully opened door, at least 460 mm (18 in) is required.
–
For a door opened at 90°, at least 32 mm (1.25 in) is required.
Ensure that there is at least 100 mm (4 in) of space around the enclosure to allow easy
access to cable conduits.
Leave adequate space below or next to the enclosure for an ICP-MAP0120 MAP
expansion enclosure kit for future additions to the system.
To minimize battery depletion, install the enclosure in locations at normal room
temperature.
Use the ICP-MAP0111 installation mounting template or the ICP-MAP0120 installation
mounting template
Unhinge and remove the enclosure door and set it aside.
Remove the enclosure knockouts in the order shown in the figure below.
3
5
1
2
Description
3
5
Installation manual
Installation | en
5
1
4
5
2024-10 | V26 | F.01U.168.332
19
5
