Modular Alarm Platform 5000
Mounting the ICP-MAP0111 MAP panel enclosure
Callout
1
2
1.
2.
Bosch Security Systems B.V.
Description
Mounting hole
Hole for screw to secure wall tamper plug
Mount the enclosure to the intended surface using suitable screws and anchors (not
supplied). Use the mounting holes as shown in the figure.
Ensure that all screws are tight and that the enclosure is securely fastened to the
mounting surface.
1
Installation manual
Installation | en
1
2
2024-10 | V26 | F.01U.168.332
