54
en | Connections
LSN gateway stub configuration
LSN Device
Callout
1
2
4.6
Splitting the external BDB with a BDB/CAN splitter
The external BDB can be splitted into two independent and isolated stubs to connect touch
keypads, gateways and further power supplies. This way, flexible wiring into different
directions with up to 500 m cable length as well as a higher reliability can be achieved.
For information on installing a BDB/CAN splitter, refer to the correspondent installation
manual and datasheet.
2024-10 | V26 | F.01U.168.332
1
Description
ICP-MAP0010 MAP LSN gateway
ICP-MAP0111 MAP panel enclosure
Installation manual
Modular Alarm Platform 5000
LSN Device
2
Bosch Security Systems B.V.
