80 en | Appendices
May walk test points
Table 9.2: Permissions
* also with Duress PIN
9.1.7

Connection of an LSN fire detector as a technical detector

Warning!
Configuration
!
The configuration of an LSN fire detector may not impact the arming function.
This means that arming needs to be possible even with a tripped detector.
Warning!
Retroactive effects
!
By connecting an LSN fire detector, no negative retroactive effects on the intrusion
functionality may happen.
Notice!
Mechanical removal lock
i
The LSN fire detector bases have a mechanical removal lock function which can be
activated or deactivated. With activating the mechanical removal lock, removing the
detector without a mechanical tool is not possible.
For a VdS compliant installation, activate the mechanical removal lock function.
9.2

Requirements in accordance with EN 50131 grade 3

Notice!
i
If not all requirements in accordance with this standard can be satisfied or only a lower
grade can be met, the compliance mark (EN 50131 grade 3) must be either removed or
adapted.
9.2.1

Selecting the default setting

1.
2.
9.2.2

Connectable peripherals

To comply with the requirements for proper functioning of the MAP5000 panel (i.e.
detection and forwarding of intrusion, hold-up, tamper and trouble states), only peripherals
may be connected that are certified in accordance with EN 50131 grade 3 or grade 4.
9.2.3

Arming / disarming without entry / exit delay

Arming outside the secured area, e.g. with arming device
1.
2.
3.
2024-10 | V26 | F.01U.168.332
Select EN50131 grade 3 as the default property values setting (refer to Standard-
compliant programming, page 65).
If the MAP5000 panel validation in accordance with EN 50131 grade 3 fails, do not
proceed with programming the MAP5000 panel.
Include a new area if not yet present.
Connect a free input with the device key switch.
Using the wizard, select the type Static or Dynamic, the user and function of the key
switch Arm / Disarm Area. Now select the area that is to be armed / disarmed. For exit
delay, select No Delay.
Installation manual
Modular Alarm Platform 5000
X
Bosch Security Systems B.V.
