Installing and connecting the tamper switch

–
–
Installing the tamper switch onto the rail
4
Tamper switch extension piece
Callout
1
Bosch Security Systems B.V.
Install the ICP-MAP0050 MAP panel/power enclosure tamper switch in the ICP-
MAP0111 MAP panel enclosure.
Install the ICP-MAP0055 MAP expansion enclosure tamper switch in the ICP-MAP0120
MAP expansion enclosure.
Slide the extension piece of the tamper switch to position C as shown in the figure
below.
If a wall tamper plug was installed (refer to Mounting the enclosure, page 22), the
position of the expansion piece of the tamper switch must be chosen in a way that
lifting the enclosure off the wall by > 5 mm leads to reliable activation of the tamper
switch.
Description
ICP-MAP0050 MAP panel/power enclosure tamper switch
2
Installation manual
Connections | en
