Modular Alarm Platform 5000
External BDB connector (1)
4
Programmable output (2)
4
Programmable dry relay output (3)
4
Output AUX (4)
4
Supervised inputs (5)
4
Input for MAP panel tamper switch (6)
4
4.4

Connecting DE module

ICP-MAP0007-2 MAP DE interface module connections
1.
2.
Connecting the DE module
Callout
1
2
3
4
Bosch Security Systems B.V.
Use this connection to connect additional system modules to the external BDB (refer to
Connecting the Bosch Data Bus, page 45 and Modules on the BDB, page 47).
Use these connections to control devices in certain system states (refer to
Programmable output signals, page 67).
Use these connections to control devices such as self-powered signaling devices in
certain system states (Programmable output signals, page 67).
Use this connection to supply voltage to devices the MAP5000 panel. The voltage can
be switched on/off in certain system states.
Use these inputs to connect supervised conventional detectors or key switches RE =
12.1 kOhm (refer to Point types and point evaluation, page 67).
Use this input to connect the tamper switch of the MAP5000 panel (refer to Connecting
the ICP-MAP0050 tamper switch, page 59).
If a supported printer is used, connect the printer to the DE module.
Connect the supervised sirens and strobes to the DE module outputs.
1
Description
Bosch Data Bus
Bosch Data Bus
Outputs (supervised)
COM2 20mA interface
7
8
6
2
Installation manual
Connections | en
3
4
5
2024-10 | V26 | F.01U.168.332
51
