Modular Alarm Platform 5000
1.
2.
AE 4 Access for manufacturers via RPS for MAP
1.
2.
3.
4.
5.
1) Activation of the warning device on opening the MAP panel enclosure may be omitted if
access to access level 3 is controlled by switches, locks (at least 15,000 variation
possibilities) or other equivalent means.
Internal warning device when control panel enclosure is opened
An internal warning device must be provided that trips a time-limited audible alarm when
the control panel enclosure is opened in unarmed state.
1.
2.
Functions of the Access Levels
The assignment of the functions to the access levels 2 and 3 can be adapted in RPS for
MAP.
Further subdivisions are possible within the access levels if the owner wishes to grant the
users different permissions: User Manager > Permission Sets
General permissions
May silence buzzer on touch keypad
May change own user passcode
May transmit/receive programming with RPS for MAP
May receive history with RPS for MAP
May perform diagnostics with RPS for MAP
May perform software updates with RPS for MAP
Operations category permissions
May disable device
May enable device
Bosch Security Systems B.V.
Open MAP panel enclosure.
Internal warning device is activated for 3 sec.
or
authorize from RPS with an AE 2 user with corresponding permissions (touch keypad:
main menu page 2 > RPS).
Establish a connection between the MAP5000 panel and RPS for MAP.
Authorize the manufacturer user with an AE 3 user with corresponding permissions
(touch keypad: main menu page 1 > maintenance page 3 > manufacturer permission).
Open MAP panel enclosure.
The internal warning device is activated for 3 sec.
Switch to installer mode = AE 3 (Installer button, page 72).
Login with the passcode of the manufacturer at the installer touch keypad
(Manufacturer authorization, page 66).
Establish a connection between the MAP5000 panel and RPS for MAP.
Assign device siren to free output.
In the properties> behavior item list of the device siren, activate the option Include
External Tamper Alarm Disarmed of Onboard Tamper.
1
Installation manual
Appendices | en
1
Access Level
1 2A 2B
X X X
X X
1 2A 2B
2024-10 | V26 | F.01U.168.332
89
3 4
X
X X
X
X
X
X
3 4
X
X
