Modular Alarm Platform 5000
ð
Switching off the installer mode
4
System restart
The system can be restarted without being de-energized.
4
ð
LED status
Off
Fast blinking
Slow blinking
Permanently lit
Restoring the initial state of the MAP5000 panel
1.
2.
Failsafe mode
Forcing failsafe mode
Programming and MAP5000 panel firmware are deleted and RPS for MAP passcode is reset
to default settings when executing this option.
1.
2.
3.
4.
5.
6.
7.
Forcing extended failsafe mode
Programming, the MAP5000 panel firmware and history are deleted and network settings
are reset (DHCP, 0.0.0.0) when executing this option.
4
Bosch Security Systems B.V.
The operating LED starts blinking slowly to indicate the installer mode.
Press the installer button on the MAP5000 panel for three seconds.
Press the installer button on the MAP5000 panel for six seconds.
The LEDs on the MAP5000 panel and all other installed modules stop indicating briefly.
The initialization phase, indicated by a blinking LED, starts.
The LEDs on the MAP5000 panel and all other installed modules start indicating and
the system is ready for operation again.
Put the panel in Failsafe mode (see below).
Update the firmware.
Open the tamper switch.
De-energize the MAP5000 panel (e.g. disconnect the small white connector at the rear
of the MAP5000 panel).
Press and hold the installer button.
Connect voltage (e.g. plug in small white connector again).
Release the installer button after 45 seconds.
Wait until operating LED is permanently lit (can take several minutes).
Transfer latest MAP5000 panel firmware "MAP_Update.Cumulative ...tar.bz2" again
using RPS for MAP.
Carry out steps 1 - 6 of the above, then carry out steps 2 - 7.
Description
No function
Connection setup
Data exchange
Operating state
Installation manual
Maintenance and service | en
2024-10 | V26 | F.01U.168.332
